5
Controls and functions
Projector
•Power
Toggles the projector between standby
mode and Power ON.
•/ (Keystone keys)
Manually corrects distorted imag
es
resulting
from an angled projection.
• Left/ Right/ Up/ Down
Selects the desired menu items and makes
adjustments when the On-Screen Display
(OSD) menu is activated.
•Menu
Turns on the On-Screen Di
splay (OSD)
menu.
•E
xit
Goes back to previous OSD menu,
exits
a
nd saves menu settings.
• Source
Displays the source selection bar.
• (
Help)
Displays the HELP menu with
a long
press
for 3 seconds.
•Blank
Hides the screen picture.
•Enter
Enacts the selected On-Screen Di
splay
(OSD
) menu item when the On-S
creen
Display (O
SD) menu is activated.
•Color Mode
Selects an available picture setup mode.
• (Volume Up)
Increases the volume level.
• (Volume Down)
Decreases the volume level.
Focus ring
Power indicator light
Lamp indicator light
Temperature indicator light
Zoom ring
