ViewSonic PJD5111 User Manual

Introduction 9
9. LAMP indicator light
Indicates the status of the lamp. Lights up
or flashes when the lamp has developed a
problem. See "Indicators" on page 46 for
details.
10. AUTO
Automatically determines the best picture
timings for the displayed image. See
"Auto-adjusting the image" on page 24 for
details.
11. Right/
Activates panel key lock. See "Locking
control keys" on page 31 for details.
When the On-Screen Display (OSD)
menu is activated, the #6, #7, and #11
keys are used as directional arrows to
select the desired menu items and to make
adjustments. See "Using the menus" on
page 20 for details.
12. MODE/ENTER
Selects an available picture setup mode.
See "Selecting a picture mode" on page 28
for details.
Enacts the selected On-Screen Display
(OSD) menu item.
13. SOURCE
Displays the source selection bar. See
"Switching input signal" on page 23 for
details.
14. FREEZE
Freezes the projected image. See
"Freezing the image" on page 32 for
details.
15. Left
Selects the desired menu items and
makes adjustments. See "Using the
menus" on page 20 for details.
16. BLANK
Hides the screen picture. See "Hiding the
image" on page 31 for details.
17. Digital Zoom keys (+, -)
Magnifies or reduces the projected
picture size. See "Magnifying and
searching for details" on page 26 for
details.
18. ViewMatch
Switch in between high brightness
performance or Accuracy color
performance.
19. Volume keys (+, -)
Magnifies or reduces the volume level.
See "Adjusting the sound" on page 32 for
details.

ViewSonic PJD5111 Specifications

General

Projection distance	1.5/6 m
Vertical scan range	50 - 87 Hz
Horizontal scan range	30 - 70 kHz
Projection technology	DLP
Contrast ratio (typical)	2800:1
Screen size compatibility	35/155 \
Projector native resolution	SVGA (800x600)
Keystone correction, horizontal	40 °
Digital zoom	1.1 x
Focal length range	21 - 23 mm
I/O ports	1 × RCA jack 1 × 4-pin mini-DIN % × 15-pin mini D-sub(RGB)
Audio input	1 × 3.5 mm mini jack
Aspect ratio	4:3, 16:9
RS-232 ports	1
Dimensions (WxDxH)	264 x 225 x 96.4 mm
Power requirements	AC100–240V, 2.9 A, 50/60 Hz
Lamp power	189 W
Light source type	Lamp
Service life of light source	3000 h
RMS rated power	5 W
Serial interface type	RS-232
VGA (D-Sub) ports quantity	5
Certification	CB, ROHS, WEEE, UL/cUL, FCC-B, ICES-003, IRAM (Argentina), NOMPSB, C-tick, EK, CE, TUV/GS, GOST-R, Hygienic, SASO UKrSEPRO, CCC
Power consumption (typical)	242 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Market positioning	Presentation

Weight and Dimensions

Weight	2300 g
