ViewSonic PJD7828HDL User Manual

67
<RS232 command table>
Function
Statu
s
Action cmd
Power
Write
Turn on 0x06 0x14 0x00 0x04 0x00 0x34 0x11 0x00 0x00 0x5D
Turn off 0x06 0x14 0x00 0x04 0x00 0x34 0x11 0x01 0x00 0x5E
Read
Power status
(on/off)
0x07 0x14 0x00 0x05 0x00 0x34 0x00 0x00 0x11 0x00 0x5E
Reset all
settings
Execute 0x06 0x14 0x00 0x04 0x00 0x34 0x11 0x02 0x00 0x5F
Reset Color
Settings
Execute 0x06 0x14 0x00 0x04 0x00 0x34 0x11 0x2A 0x00 0x87
Splash
Screen
Write
Splash Screen
Black
0x06 0x14 0x00 0x04 0x00 0x34 0x11 0x0A 0x00 0x67
Splash Screen
Blue
0x06 0x14 0x00 0x04 0x00 0x34 0x11 0x0A 0x01 0x68
Splash Screen
ViewSonic
0x06 0x14 0x00 0x04 0x00 0x34 0x11 0x0A 0x02 0x69
Splash Screen
Screen
Capture
0x06 0x14 0x00 0x04 0x00 0x34 0x11 0x0A 0x03 0x6A
Splash Screen
Off
0x06 0x14 0x00 0x04 0x00 0x34 0x11 0x0A 0x04 0x6B
Read
Splash Screen
status
0x07 0x14 0x00 0x05 0x00 0x34 0x00 0x00 0x11 0x0A 0x68
Quick
Power Off
Write
Quick Power
Off Off
0x06 0x14 0x00 0x04 0x00 0x34 0x11 0x0B 0x00 0x68
Quick Power
Off On
0x06 0x14 0x00 0x04 0x00 0x34 0x11 0x0B 0x01 0x69
Read
Quick Power
Off status
0x07 0x14 0x00 0x05 0x00 0x34 0x00 0x00 0x11 0x0B 0x69
High
Altitude
Mode
Write
High Altitude
Mode Off
0x06 0x14 0x00 0x04 0x00 0x34 0x11 0x0C 0x00 0x69
High Altitude
Mode On
0x06 0x14 0x00 0x04 0x00 0x34 0x11 0x0C 0x01 0x6A
Read
High Altitude
Mode status
0x07 0x14 0x00 0x05 0x00 0x34 0x00 0x00 0x11 0x0C 0x6A
Lamp Mode
Write
Normal 0x06 0x14 0x00 0x04 0x00 0x34 0x11 0x10 0x00 0x6D
Economic 0x06 0x14 0x00 0x04 0x00 0x34 0x11 0x10 0x01 0x6E
Dynamic 0x06 0x14 0x00 0x04 0x00 0x34 0x11 0x10 0x02 0x6F
Sleep Mode 0x06 0x14 0x00 0x04 0x00 0x34 0x11 0x10 0x03 0x70
Read
Lamp Mode
status
0x07 0x14 0x00 0x05 0x00 0x34 0x00 0x00 0x11 0x10 0x6E

ViewSonic PJD7828HDL Specifications

General

TV Tuner	no
White Brightness	3200 lumens
Resolution	full hd (1080p)
Native Resolution	1920 x 1080
Contrast Ratio	22000:1
Aspect Ratio	16:9
Throw Ratio Range	1.15~1.5:1
Keystone Effect	yes
3D	yes
Minimum Screen Size	30 inches
Maximum Screen Size	300 inches
Digital Zoom	yes
Minimum Distance	4.2 feet
Maximum Distance	46.9 feet
HDMI Ports	2
USB Ports	2
RS-232 Port	1
Video Input	composite video, hdmi
Inputs	composite video, hdmi, usb
Remote Control	yes
OS Compatibility	mac, windows

Weight and Dimensions

Depth	4.08 inches
Height	8.98 inches
Width	12.44 inches
Net Weight	5.3 pounds
