VIKING TECHNICAL SUPPORT 1.800.908.0884
39
TROUBLESHOOTING
LCD Display References
LCD MSG Meaning
Page 41
TS Ref #s
Multi Meter Displays
MOT AMP
__._ A
This is the motor current amperage during operation.
MOT VOLT
__._ VDC
This is the actual motor voltage during operation.
SOL VOLT
__._ VAC
This is the actual voltage from the solar panel.
CHARGE
__._ VDC
Indicates the voltage being supplied to the Control Board from the Viking
Solar Charger.
BAT VOLT
__._ VDC
This is the actual voltage from the Battery
Board Settings Messages
EPS2
___% ERR
Indicates that the Electronic Positioning Sensor (EPS) needs to be tuned.
Error rate is displayed as a percentage
Speed
__%
Shows the percentage of speed set by the Speed adjustment on the control
board. (pg 24)
OVERLAP
_._ SEC
Shows the number of seconds set by the Overlap Adjustment on the
control board. This feature is not available on slide gate operator models
ODS SENS
___%
Shows the force setting selected to trip the obstruction sensor. (pg 26)
TIMER
__ SEC
Shows the amount time set or remaining to hold the gate at the Open Limit
position, before the gate starts to close. (pg 24)
