TROUBLESHOOTING
LCD Display References
LCD MSG Meaning
Page 41
TS Ref #s
Error Messages
ERR EPS2
WRONG
The EPS (Electronic Positioning Sensor) has one of the following
conditions: a) The EPS is not properly adjusted b) The EPS has a potential
connection problem c) The EPS has the wrong cable harness
?
ERR EPS2
MISSING
Missing or damaged EPS2 cable harness
14, 17
ERR ___
LIMIT
Indicates that the open “OPN”, close “CLS“ or both “NO“ limits are cleared
and need to be set.
6
ERR FUSE
15 AMP
15 Amp motor fuse is blown
7, 11, 12
Er PANEL
LOW
Indicates that the voltage being provided from the solar panel is too low.
?
ER PANEL
HIGH
Indicates that the voltage being provided from the solar panel is too High.
?
ER SOLAR
NO PANEL
Indicates that there is no voltage being provided from the solar panel
?
ERR NO
Sol UNIT
Indicates that there is no voltage being provided from the solar panel.
?
ERR CHRG
HIGH
Potential problem with the Solar Charger.
?
ERR BAT
LOW
The battery is low
?
ERR SENS
UL RO
There is a problem with the required monitored sensor(s) connected
to the “UL” and/or “Re-Open” input terminals (pg 10-11, 23, 28-29).
22
