Wireless Communication Options
PRIMARY/SECONDARY SETUP
REQUIRED ADD-ON:
Viking Konnect - Wireless Primary/Secondary Kit PART# VA-KONNECT-MS
Green LEDs will be illuminated
solid when communication is ON.
Step 1
Plug the modules on to the “V.K” plug & play
connection of each operators Control Board. It is not
important which board the Primary or Secondary
module is placed on.
! Technical Tip: DO NOT set the “Timer” and/or “Overlap” features on both operators
Control Boards. Only turn these features on at the Primary Control Board.
DUAL MODE
ON
Step 3
At the Secondary Operator:
Turn ON the DUAL MODE Feature:
•
Toggle the “Diagnose” button until you see DUAL MODE
on the LCD Display.
•
Default setting is OFF.
•
Press and hold the “Stop” button.
•
Toggle the “Diagnose” button once.
•
The feature should now be displayed as ON.
Step 2
At the Primary Operator:
Connect the entrapment protection sensor(s) as
described on pages 7 and 18.
To Next Page
