VIKING TECHNICAL SUPPORT 1.800.908.0884 L-3 • Rev K1 • November 2022
1
TABLE OF CONTENTS:
IMPORTANT SAFETY INFORMATION 2-9
Important Safety Instructions 2
Important Installation Instructions 2-3
Maintenance 4
General Safety Precautions 4-5
UL325 Gate Operator Classifications 5
Monitored Entrapment Protection Requirements 6
Monitored Entrapment Protection Installation 7
Manual Release 7
Audible Alarm Reset Installation 8
Warning Placard Installation 9
SPECIFICATIONS 10
CONTROL BOARD REFERENCES
11
GATE OPERATOR INSTALLATION
12-15
Concrete Pad Option 12
Post Mounting Option 13
Operator Positioning 14-15
ELECTRICAL INSTALLATION 16-18
High Voltage Supply Option 16
Low Voltage Supply Option 17
Solar Supply Option 17
Monitored UL Sensor Connections 18
LIMITS SETUP 19
PRIMARY/SECONDARY SET UP 20-21
Two Wire Communication 20
Wireless Communication Options 21
CONTROL BOARD SETUP 22-25
Initial Settings 22-23
Obstruction Detection Sensor (ODS) 24
Heater, Lock Mode................................................................................................................. 25
ACCESSORY CONNECTIONS 26-33
Access Control Connections 26-27
Radio Receiver 28
Photocell 29
Viking Loop Rack 30
Guidelines for Loop Installations 31
Magnetic Lock, Lock Solenoid 32
Barrier Arm Synchronization Option 33
TROUBLESHOOTING 34-40
LED References 34-35
LCD Display References 36-39
Solutions 40
PARTS DIAGRAM/PARTS LIST 41
LIMITED WARRANTY 42-43
VIKING ACCESSORIES 44
