Viking Heater
The operator has an integrated heater that is thermostatically controlled. Activate this
feature when the operator is used in application temperatures down to -20°F (-29°C).
Viking Lock Mode
Turning this feature ON will secure the gate at the closed position, preventing unauthorized
manual entry. ! IMPORTANT: The EPS2 cable must be connected for this feature to function.
CONTROL BOARD SETUP
HEATER
CLS ON
To set the heater to turn on at the Close Limit:
1.
Use the “Diagnose” button to scroll through the LCD
Display to “HEATER CLS”
2.
Press and hold the “Stop” button on the Control Board.
3.
Press and release the “Diagnose” button to turn this
feature ON and OFF.
HEATER
OPN ON
To set the heater to turn on at the Open Limit:
1.
Use the “Diagnose” button to scroll through the LCD
Display to “HEATER OPN”
2.
Perform steps 2-3 as described above.
NOTE: If the application requires the gate
to be held open for any reason, set the
HEATER ON for both limit positions.
! IMPORTANT: A POSITIVE STOP must be
used on the gate at the limit position(s)
the HEATER has been set for.
LOCK MOD
ON
Use the LCD Display to activate this feature.
1.
Use the “Diagnose” button to scroll through the LCD menu to “LOCK MOD”
2.
Press and hold the “Stop” button on the Control Board.
3.
Press and release the “Diagnose” button to turn this feature ON and OFF.
