VIKING TECHNICAL SUPPORT 1.800.908.0884
37
TROUBLESHOOTING
LCD Display References
LCD MSG Meaning
Page 40
TS Ref #s
EPS2
____
Status of the EPS2 Sensor.
“OK”= EPS2 Sensor signal is good but is the only sensor controlling the limits.
“STANDBY”= EPS2 is monitoring the limit positions secondarily to SPS Sensor.
“MISSING” = EPS2 Sensor is disconnected from the Control Board. (pg 11 @6).
“NOT SET” = EPS2 Sensor was reconnected. Clear and Reset both limits. (pg 19)
14
SPS
____
Status of the SPS Sensor.
“OK”= SPS Sensor signal is good and controlling the limit positions .
“LEARNING” = SPS Sensor is performing a learn cycle.
“MISSING” = SPS Sensor is disconnected from the Control Board (pg 11 @24).
17
RED CONN
UNPLUGED
The Motor Connector is not plugged into the red Open Left or Open Right socket at
the Control Board. (pg 19)
21
Multi Meter Displays
MOT AMP
__._ A
This is the motor current amperage during operation
MOT VOLT
__._ VDC
This is the actual motor voltage during operation
AC VOLT
__._ VAC
This is the actual low voltage AC to the Control Board from the transformer
CHARGE
__._ VDC
Indicates the charging voltage to the batteries, if the Battery Switch is in the OFF
position.
BAT VOLT
__._ VDC
Indicates battery voltage, if the AC power is discontinued to the Control Board.
Board Settings Messages
Speed
__ %
Shows the percentage of speed set by the Speed adjustment on the Control Board.
(pg 22)
ODS SENS
___%
Shows the force setting selected to trip the obstruction sensor. (pg 22, 24)
TIMER
__ SEC
Shows the amount time set or remaining to hold the gate at the Open Limit position,
before the gate starts to close. (pg 22)
HEATER
___ OFF
The Integrated Heater is disabled for the open “OPN” and/or close “CLS” limits (pg
25)
HEATER
___ ON
The Integrated Heater has been enabled to turn on at the open “OPN” and/or close
“CLS” limits (pg 27) “ACTV” will also be displayed while it is heating.
LOCK MOD
___
The Lock Mode feature is turned ON or OFF (pg 25)
