Service Diagnostics and Procedures
Child Lock Switch
1. Remove cavity cover (follow cavity cover
disassembly procedure).
2. Test switch. Lock switch should read 0
Ω
when
the switch is in the “–“position and should read
infinite
Ω
in the “O“ position.
3. If switch is found to be defective, replace entire
cavity cover assembly (see page 71).
Dispenser Light Socket
1. Remove cavity cover (follow cavity cover
disassembly procedure).
2. Test switch.
3. If switch is found to be defective, replace entire
cavity cover assembly (see page 71).
WARNING
To avoid risk of electrical shock, personal injury, or death, disconnect electrical power to unit using power
switch before servicing. Wires removed during disassembly must be replaced on proper terminals to insure
correct earth ground and polarization. After servicing, reconnect power using power switch.
Child Lock Switch
Dispenser Light Socket
