Vinten flowtech 75 - Attach Optional Ground Spreader flowtech 75; 100


Installation
Attach Optional Ground Spreader owtech 75 / 100
!
CAUTION! Ensure the ground spreader legs are all the
same length before attempting to fold the tripod with the
spreader attached. Failure to observe this procedure could
lead to damage of the Ground Spreader
The tripod is delivered with the Hinge Lock in the OFF
position for use with a spreader.

1. 
2. Place the tripod foot on the ball of the spreader foot.
Ground Spreader shown in the
stored position
