Vinten flowtech 75 - Leg Friction Adjustment

23
Leg Friction Adjustment
1. Should the leg friction require adjustment, open the legs to gain

2. 
!
CAUTION! Do not adjust more than required as this
will lead to increased wear and stress on the leg
friction components and damage to the bowl.
Maintenance
5
2
4
6
3
1
3. 

4. Always tighten the screws in an opposite pattern
following the numbered pattern in the diagram.
5. If a torque screwdriver is not available, use a Hex
Key; follow the pattern in the diagram, but only
tighten the screws by a small amount taking care
not to over-tighten.
6. Test the legs for correct friction and adjust again if
necessary.
