Installation
Attach Optional Mid-Level Spreader
CAUTION! Ensure the latching pins are fully engaged with
the locating holes in the tripod. Failure to attach correctly
could result in damage to the equipment
The tripod is delivered with the Hinge Lock in the OFF
position for use with a spreader.
1. Hold the spreader between thumb
release buttons on each side.
2. Align the latching pins with the locating
holes on the tripod leg.
3. Release the buttons to lock the
spreader in place.
4. Unlock the spreader arms to allow the arms to extend as required.
5. Tighten the spreader locks when the tripod legs are in the correct
position.
Installation
Cleaning.
with clean water.
