Opening Tripod Legs
1.
2.
Installation
3.
a. As a safeguard against accidental collapse the leg must be
moved inwards slightly
1
to relieve the tension on the lock.
b. Push the lock slider down
2
and pull the leg outwards
3
.
The angle of each leg can be adjusted independently of the
other two legs.
1
2
3
Repeat for the remaining legs.
