Vinten flowtech 75 - Installation; Setting up the Tripod

6
Installation
Setting up the Tripod
1. The legs are secured using magnetic catches. Pull the legs from
the bottom to separate.
Note! If preferred this step may be performed after step 3.
2. Place the tripod on the ground. Lift the quick release levers fully
and raise the tripod to the required height.
1
2 3
!
WARNING! Tripod spiked feet can be dangerous. Always
place tripod on the ground before releasing quick release
levers.
3. With the correct height achieved, lower the quick release levers to
lock the legs in position.
!
WARNING! 󰀩

