Installation
3. Bend the rubber strap
1
and engage the bottom edge of the
lever in the tripod recess.
4. Lift the lever
2
upwards towards the tripod until it locks in place.
Repeat for all three legs.
2
1
5. Tripod spiked foot secured in the Ground Spreader Foot.
Operation of Ground Spreader
1. When assembled on the tripod, use your foot to press and hold
2. Extend the inner arm to the required length and release the
Release Button
Inner Arm
NOTE! The inner arm should not be forced back against
the mechanism, always hold the release button down
whilst extending or retracting the inner arm.
to visually set the length of the spreader arms.
If the spreader will not go into the desired position, check
