table of zones
The zone number is the number of LED flashes used by the
system to identify that input. The standard input assignments
are listed below, along with spaces to write in any optional
sensors or switches you have had installed.
Zone - Number Dealer-Installed
of LED Flashes Description Options
1 Instant trigger - often used
for trunk pinswitches
2 Shock sensor input - a light
impact activates warn away
and a heavier impact activates
full alarm.
3 Door switch trigger
4 Optional sensor inputs for
warn away and full
alarm notification.
5 Ignition trigger
6 Hood trigger
7 Optional sensor inputs for
warn away and full
alarm notification.
➜
