Viper 600 ESP - Negative-Triggered, Relay Driven Systems (Type B); Reversing Polarity (Type C)

© 1999 Directed Electronics, Inc. Vista, CA 21
H2/A
H2/B
H2/C
H2/D
H2/E
H2/F
H2/G
H2/H
TRUNK
RELEASE
RELAY
TO H1/12
DOMELIGHT
SUPERVISION
RELAY
TO H1/4
LOCK
RELAY
UNLOCK
RELAY
#87
#87A
#30A
#87
#87A
#30A
RED/WHITE CHANNEL 2 RELAY INPUT #87
BLACK/WHITE DOMELIGHT SUPERVISION INPUT #87
GREEN/BLACK LOCK #30 COMMON (OUTPUT)
WHITE/BLACK LOCK #87A NORMALLY CLOSED
VIOLET/BLACK LOCK #87 NORMALLY OPEN (INPUT)
BROWN/BLACK UNLOCK #87A NORMALLY CLOSED
BLUE/BLACK UNLOCK #30 COMMON (OUTPUT)
VIOLET UNLOCK #87 NORMALLY OPEN (INPUT)
15A
MOTOR(+)
LOCK WIRES
+12V CONSTANT
(15A CAPABLE)
X CUT X
X CUT X
MOTOR(+)
UNLOCK WIRES
(+) 12V
LOCK UNLOCK
type C: reversing polarity
LOCK UNLOCK
H2/A
H2/B
H2/C
H2/D
H2/E
H2/F
H2/G
H2/H
TRUNK
RELEASE
RELAY
TO H1/12
DOMELIGHT
SUPERVISION
RELAY
TO H1/4
LOCK
RELAY
UNLOCK
RELAY
#87
#87A
#30A
#87
#87A
#30A
NOT USED
NOT USED
VEHICLE (-)
LOCK TRIGGER
CIRCUIT
VEHICLE (-)
UNLOCK TRIGGER
CIRCUIT
FACTORY LOCK
SWITCH
TO FACTORY
RELAYS
RED/WHITE CHANNEL 2 RELAY INPUT #87
BLACK/WHITE DOMELIGHT SUPERVISION INPUT #87
GREEN/BLACK LOCK #30 COMMON (OUTPUT)
WHITE/BLACK LOCK #87A NORMALLY CLOSED
VIOLET/BLACK LOCK #87A NORMALLY OPEN (INPUT)
BROWN/BLACK UNLOCK #87A NORMALLY CLOSED
BLUE/BLACK UNLOCK #30 COMMON (OUTPUT)
VIOLET UNLOCK #87 NORMALLY OPEN (INPUT)
15A
TO CHASSIS
GROUND
type B: negative-triggered, relay-driven systems
