Vision VE-810 User Manual

36 VE810 Engraver Manual
(Figure 3.2) The Edge Guides
Edge Guides
Ed g e G u id e
Thumbscrews
Ed
g
e Guide Thumbscrews
To adjust the edge guides, place the material you would like to engrave in the home
position. The edge guides should be level or slightly below the engraving material. If they
are not, loosen the edge guide thumbscrews and lower the edge guides. Tighten the
edge guide thumbscrews. The edge guides are now adjusted properly.
