Page.32.
Application
A. When maintaining the dome camera, the tester sends out the colour bar by its BNC output to
the monitor at the monitoring center. If the monitor receive the colour bar, it means the video
transmit channel works normally. Meanwhile on the basis of the received colour bar, the
monitoring center can judge if transmission has loss or interference.
B. The tester sends out the pure colour bar (such as white and black colour), to test the monitor
whether has bright or black dots
C. The tester sends out video signal image to test if the image received by the monitor has
excursion.
3.3.4 ONVIF
ONVIF test with Rapid and HD mode type, while in Rapid ONVIF, tester can quickly search
camera, auto log in and display image from the camera. While in HD mode, the tester can
fluently display the image up to 1080P.
Click icon to enter the ONVIF app. The icon of ONVIF is Rapid mode，The icon of HD
ONVIF is HD mode.
