Vista DIAMOND - Operation and Core Functions; Initial Setup and Connections

Page.15.
27
Video signal output（BNC interface）/ cable tracer interface
28
Optical power meter interface (Optional)
29
LED lamp
30
RS485 Interface: RS485communication for the PTZ
31
RS232 Interface: RS232 communication for the PTZ
32
TDR cable test interface (Optional)
33
HDMI output interface
34
Micro SD card moveable,(comes with 4GB, supports up to 32GB)
35
UTP cable port: UTP cable tester port/ Cable tracer port
36
Audio output and earphone interface
37
Audio input
38
PSE power sourcing equipment. Tests PoE voltage
39
PoE power supply output or LAN test port (Use to test PoE or non-PoE IP camera)
40
USB 5V 2A power output (used only for power, not data)
41
DC12V2A charging interface
42
DC12V2A power output , for provisional DC power supply
3. Operation
3.1 Installing the Battery
The tester has built-in lithium ion polymer rechargeable battery. The battery cable inside the
monitor is disconnected for safety during transportation!
Prior to the use of the instrument, the battery cables inside the monitor should be
connected.
Usually it doesn’t need to disconnect the cable at the normal use
Pressing the key continuously can power on or off the tester.
Notice: Pls use the original adaptor and connected cable of the device!
