3.4 Audio test
You can test the audio input from audio pickup devices by connecting the audio pickup device
to the IP tester with the supplied audio cable.
3.5 HDMI output
The built in HDMI output port can output live video from an analogue or IP camera, recorded
files, media files and images to HDTV monitors. Connect an HDMI cable from the IP tester to
an HDTV monitor at any time. It supports up to 1080P resolution.
3.6 PoE power output
The IP tester supports PoE (Power over Ethernet) output to an IP camera via the LAN port.
Data transmission and 48VDC use the network cable’s 1, 2, 3, and 6 pins to deliver power. If
the IP camera supports PoE, you can directly connect to the camera without the use of an
external power supply.
Notice
a. Please make sure the cable connected to the tester’s Lan port is straight-line cable and has
no short circuit, otherwise will damage the tester
b. Before using PoE power output, pls check the IP camera whether supports POE powered.
