E3D320VX/E3D420VX/E3D470VX
SettingtheTimeZone
To ensure the correct time is displayed when you press the INFO button, set the
TV’s time zone:
To have the TV display the correct time, you must be connected to
the internet via an Ethernet cable or a wireless network.
1. Press the MENU button on the remote.
The on-screen menu is displayed.
2. Use the Arrow buttons on the remote
to highlight the Settings icon and
press OK. The Settings menu is
displayed.
3. Use the Arrow buttons on the remote
to highlight Time & Local Settings
and press OK. The Time & Local
Settings menu is displayed.
4. Highlight Time Zone and press OK.
The Time Zone menu is displayed.
5. Highlight your time zone and press OK.
6. Highlight Daylight Savings and press
OK. The Daylight Savings menu is
displayed. Choose On if daylight
savings is in effect, or Off if it is not.
7. Highlight Postal Code. Enter your
ZIP code using the keypad on the
remote, then press OK. The ZIP code
information is often used by VIA
Apps to give you the most accurate
location-based information, such as
weather or news.
8. Press the EXIT button on the remote.
AdjustingtheCECSettings
The CEC function on your TV enables you to control HDMI-connected devices
with the included remote without any additional programming.
Not all HDMI devices support CEC. See your device’s user manual
for details.
To enable, disable, or adjust CEC settings:
9. Press the MENU button on the remote.
The on-screen menu is displayed.
10. Use the Arrow buttons on the remote
to highlight the Settings icon and
press OK. The Settings menu is
displayed.
11. Use the Arrow buttons on the remote
to highlight CEC Settings and press
OK. The CEC Settings menu is
displayed.
12. Use the Arrow and OK buttons to
adjust each setting:
• CECFunction-TouseCEC,you
mustselectEnable.
• SystemAudioControl-When
systemaudiocontrolison,you
cancontrolyourdevice’saudio
usingtheTV’sremotecontrol.
• DeviceDiscovery-Usethis
functiontodetermineifyourdevice
isconnectedandsupportsCEC.
13. Press the EXIT button on the remote.

Vizio E3D420VX Specifications

General

Child lock	No
Plug and Play	Yes
Image formats supported	JPEG XR
Video formats supported	MPEG
Display diagonal	42 \
Display technology	LCD
Supported video modes	1080p
Contrast ratio (dynamic)	150000:1
Display number of colors	1.073 billion colors
Supported graphics resolutions	1920 x 1080 (HD 1080)
Certification	CSA, CSA-US, FCC Class B, HDMI V1.4 incl. CEC. ARC, VIZIO PQA, VIZIO AQACSA, CSA-US, FCC Class B, HDMI V1.4 incl. CEC. ARC, VIZIO PQA, VIZIO AQA
Wi-Fi standards	Wi-Fi 4 (802.11n)
Audio (L/R) out	1
HDMI ports quantity	3
SCART ports quantity	0
USB 2.0 ports quantity	2
Product color	Black
Panel mounting interface	200 x 200 mm
Backlight type	CCFL
Power consumption (standby)	1 W
Power consumption (typical)	93 W
RMS rated power	10 W
Tuner type	Digital
Digital signal format system	ATSC

Weight and Dimensions

Depth (without stand)	228 mm
Width (without stand)	1021 mm
Height (without stand)	701 mm
Weight (without stand)	15013 g
