E3D320VX / E3D420VX / E3D470VX
Photo Viewer Screen
Folder Contents
This area displays the
contents of the currently
selected folder. You can
browse between files using
the Arrow and OK buttons
on the remote.
Current Folder
Displays the folder path.
Page Information
If your USB thumb drive has more files than
can be displayed on a single screen, you can
move between pages by highlighting this
area and pressing Left/Right Arrow.
Back Button
Highlight and press OK to
return to left column.
Connected Sources
Displays connected
USB devices. To change
source, highlight it and
press OK.
Current Folder
Back Button
Highlight this button and press
OK if you would like to return
to the previous screen.
Sort by Name or Date
View Thumbnails or List
View Folder Settings
Toggle Music/Photos
Start Fullscreen Slideshow
Photo Infomation
Displays name, resolution,
and file size for currently
selected photo.

Vizio E3D420VX Specifications

General

Child lock	No
Plug and Play	Yes
Image formats supported	JPEG XR
Video formats supported	MPEG
Display diagonal	42 \
Display technology	LCD
Supported video modes	1080p
Contrast ratio (dynamic)	150000:1
Display number of colors	1.073 billion colors
Supported graphics resolutions	1920 x 1080 (HD 1080)
Certification	CSA, CSA-US, FCC Class B, HDMI V1.4 incl. CEC. ARC, VIZIO PQA, VIZIO AQACSA, CSA-US, FCC Class B, HDMI V1.4 incl. CEC. ARC, VIZIO PQA, VIZIO AQA
Wi-Fi standards	Wi-Fi 4 (802.11n)
Audio (L/R) out	1
HDMI ports quantity	3
SCART ports quantity	0
USB 2.0 ports quantity	2
Product color	Black
Panel mounting interface	200 x 200 mm
Backlight type	CCFL
Power consumption (standby)	1 W
Power consumption (typical)	93 W
RMS rated power	10 W
Tuner type	Digital
Digital signal format system	ATSC

Weight and Dimensions

Depth (without stand)	228 mm
Width (without stand)	1021 mm
Height (without stand)	701 mm
Weight (without stand)	15013 g
