VIZIO VM60P HDTV User Manual
Version 3/26/2007 18
www.VIZIO.com
For Cable or Satellite Boxes with DVI:
1. Turn off the power to the Plasma HDTV and HDTV Set-
Top Box.
2. Using a HDMI-DVI cable, connect the DVI end to your
HDTV Set-Top Box and the HDMI end to the HDMI 4
Input (white color area) at the rear of the Plasma HDTV.
3. Using an audio cable (white and red connectors),
connect the cable to the audio output connectors
associated with the DVI output on your HDTV Set-Top
Box and connect the other end to the audio connectors
associated with the HDMI 1 input (white area) at the rear
of the Plasma HDTV.
4. Turn on the power to the Plasma HDTV and HDTV Set-
Top Box.
5. Select HDMI 4 using the INPUT button on the remote or
side of the Plasma HDTV, or directly by pressing the HDMI
button on the Remote Control.
Note: The HDMI Input is for HD Video and will only support 640x480 at 60Hz from a PC. Use the RGB
PC input for a greater selection of PC formats.
Note:
a) The HDMI input on the Plasma TV supports High-bandwidth Digital Content Protection
(HDCP). HDCP encrypts the transmission between the video source and the digital
display for added security and protection.
b) Refer to your HDTV Set-Top Box user manual for more information about the video
output requirements of the product or consult your cable or satellite operator.
