WBV.PU.002.EN VX136Q V2.0
6.6.2 Hydraulic drive
Connection to the energy supply may only be established by qualified technical personnel following
installation in the pipe.
Risk of infection from hydraulic oil!
Leakages can occur due to seal faults.
• Personnel must wear suitable protective clothing.
• The connection to the power supply must be established by qualified technical personnel.
In the event of injuries with hydraulic oil, consult a doctor immediately!
In addition, also read and observe the following: "Technical information for hydraulic motor"
Hydraulic hose lines
Pos: 138 /WBV/P umpen/Warnhin weise/Maschi nengefahr/Hydra ulikmotoren bei Pumpen mit hydraulische m Antrieb @ 61\ mod_1317991 178246_6.doc x @ 320128 @ @ 1
• Before connecting hydraulic hoses, read and follow the manufacturer’s specifications for hydraulic
motors.
• Observe the permissible hydraulic pressure and the permissible delivery rate.
• Connect the overflow oil line in accordance with the manufacturer's instructions.
• Replace hydraulic hose lines that show signs of damage or ageing. Only use genuine Vogelsang
hydraulic hose lines.
• The date of manufacture of the hydraulic hose line is displayed on the pressing component of the
connector. The period of usage for the hydraulic hose line should not exceed 6 years (although 5
years is recommended), including a possible storage period of no more than 2 years.
Pos: 139 /WBV/P umpen/Warnhin weise/Hinweis/ Anschließen H ydraulikmotor @ 61\mod_ 1317734946024_ 6.docx @ 31 8350 @ @ 1
Installing two hydraulic motors
When two hydraulic motors are installed, they are operated parallel and the torques of both motors are
added.
Pos: 140 /WBV/P umpen/Warnhin weise/Maschi nengefahr/Steu ergerät - Hydra ulikmotor @ 86\mod_1354 611286450_6.d ocx @ 450235 @ @ 1
Control unit
In the event of high hydraulic motor speeds, never suddenly set the control unit to "lock position" in order to
avoid pressure peaks. Whenever possible, switch from "operation" to "floating position".
