Vogelsang VX136Q - 10 Troubleshooting; 10.1 Troubleshooting; 10.2 Help

Troubleshooting
WBV.PU.002.EN VX136Q V2.0
67
10 Troubleshooting
10.1 Troubleshooting
Troubleshooting
Help  Chapter "Help"
• No pump delivery
A, B, D, E, G, J, R
• Pump stops after start
J, K, M, R, S, V
• Intake flow breaks away after start
D, E, G, S, V
• Irregular pump delivery
D, E, G, J
• Capacity too low
D, G, J, R, S, T, U
• Pump blocked
C, F, J, K, M, R, U, V
• Power consumption too high
C, M, R, S, V
• Drive belt slips
F, H, M, R, S
• Leakage on the pump
C, R, U
• Pressure and level variations in the buffer chamber
O, U, V, W
• Leakage at the mechanical seal
P, W
• Extreme pressure and level changes in the buffer
chamber
P
• With a dry buffer chamber:
buffer chamber tank more than half full
Q
• Pump too hot
A, C, M, N, R, S, U
• Motor too hot
C, K, L, M, R, S, V
• Noises & vibrations
C, D, E, F, G, I, J, K, M, N, R, S
10.2 Help
Possible cause
Possible remedy
Observe notices and
safety notes  Chapter
A
Pump is not priming
Fill the pump with fluid.
B
Incorrect direction of rotation
Change the pump's direction of rotation.
"Flow direction"
C
Pipe causing pump housing
warping
Check the orientation of the pipe to the pump.
If necessary, provide a compensator or secure the
pipe.
"Installation in pipes"
D
Leakage in the suction pipe
Check the suction-side pipe system for leakage.
Gas formation
Vent the suction pipe and pump chamber, top up
fluid.
E
Suction pipe clogged
Check the free flow of the pipe system on the
suction side.
F
Foreign matter in medium
Clean the pump unit. Install strainer in the suction
pipe.
G
NPSH
a
too low (medium
evaporates during feeding)
Increase the suction pipe diameter, shorten the
suction pipe length, simplify suction pipe assembly,
reduce the suction height, reduce the speed, adjust
the medium temperature.
"Installation in pipes"
H
Belt tension too low
Tighten in accordance with manufacturer's
specifications.
"Base, support surface for
machine"
I
Coupling not correctly
aligned
Check the orientation and align according to
manufacturer's specifications if necessary.
J
Belt drive slips
Tighten in accordance with manufacturer's
specifications.
