Void Cyclone Series - Cyclone 55 Key Features; Cyclone 55 Specifications

Cyclone Series User Guide V1.0
Page 10
5.2 Cyclone 55
5.2.1 Key features:
• Compact fibreglass enclosure
• Non-resonant structure
• Wide dispersion pattern
• Marine-grade stainless steel fittings
• UV resilient paint
• Custom colours available
5.2.2 Cyclone 55 specifications
Frequency response 70 Hz - 23 kHz ±3 dB
Eciency
1
92 dB 1W/1m
Crossover points 3.6 kHz passive
Nominal impedance 16 Ω
Power handling
2
120 W AES
Maximum output
3
110 dB cont, 114 dB peak
Driver configuration 2 x 5” LF, 2 x 1” soft dome HF tweeters
Dispersion 110°H x 70°V
Connectors Phoenix connectors with link out
Height 192 mm (7.6”)
Width 309 mm (12.2”)
Depth 207 mm (8.1”)
Weight 3.2 kg (7.1 lbs)
Enclosure Fibreglass
Rigging Included Easy Hang wall bracket
Finish Smooth cellulose
1
Measured in half space
2
AES2 - 1984 compliant
3
Calculated
Figure 5.4: Horizontal directivity isobars Figure 5.5: Vertical directivity isobars
5 Specifications and dimensions
