Cyclone Series User Guide V1.0
Page 11
309 (12.2”)
192 (7.6”)
207 (8.1”)
192 (7.6”)
309 (12.2”)
207 (8.1”)
309 (12.2”)
192 (7.6”)
207 (8.1”)
309 (12.2”)
2-M6
5.2.3 Cyclone 55 dimensions
Figure 5.6: Dimensions
5 Specifications and dimensions
