Void Cyclone Series User Manual

Cyclone Series User Guide V1.0
Page 27
Figure 8.7: Venu Series Ceiling Mount Bracket
Parts required:
• Venu Series Ceiling Mount Bracket
Figure 8.8: Cyclone bolt removal
Step 1:
Remove all four M8 bolts from the rear of the
loudspeaker.
Step 2:
Lift the loudspeaker into position and attach all
four M8 bolts.
Take care when mounting the
bracket to the ceiling, making sure
to use the correct fixing and that
the ceiling can take the load, for
example do not attach the bracket to
a suspended ceiling.
Figure 8.9: Fixing bracket
8.3 Cyclone 10 ceiling mounting
