Page 32
8.5 Horn rotation for mounting in landscape mode
Figure 8.20: Rotating horn
Step 4:
Rotate the horn and return it to its position within
the enclosure and redo all four screws.
Figure 8.21: Refitting the grill
Step 5:
Pull the cable ties toward the opposite edge of
the loudspeaker and then lower the grill into
position.
Step 5:
Remove the cable ties.
Figure 8.22: Removing cable ties
