Void Cyclone Series User Manual

Cyclone Series User Guide V1.0
Page 12
5.3 Cyclone Bass
5.3.1 Key features:
• Compact fibreglass enclosure
• Marine-grade stainless steel fittings
• UV resilient paint
• Custom colours available.
5.3.2 Cyclone Bass specifications
Frequency response 40 Hz - 160 Hz -3 dB
Eciency
1
97 dB 1W/1m
Crossover points 80 Hz - 160 Hz Active
Nominal impedance 8 Ω
Power handling
2
600 W AES
Maximum output
3
123 dB cont, 129 dB peak
Driver configuration 1 x 12”
Connectors Phoenix connectors with link out
Height 370 mm (14.6”)
Width 490 mm (19.3”)
Depth 455 mm (17.9”)
Weight 33.5 kg (73.9 lbs)
Enclosure Fibreglass
Finish Smooth cellulose
1
Measured in half space
2
AES2 - 1984 compliant
3
Calculated
5 Specifications and dimensions
