Cyclone Series User Guide V1.0
Page 28
Figure 8.10: Attaching bracket to loudspeaker
Figure 8.11: Loudspeaker positioning
Step 3:
With the lifting gear in place adjust the angle
of the bracket using the bolt on the bracket
assembly.
Step 4:
Tighten the bolt on the bracket to fix the
loudspeaker in position.
8.3 Cyclone 10 ceiling mounting
