40
Voith Turbo H + L Hydraulic GmbH & Co. KG
25000057510-TED-ENX-04
1. Close the pressure and suction valves.
2. Position drain trays below the pump to collect the uid.
3. Unscrew the pipelines on the pump, and place plastic plugs in the pump
connection openings.
4. In the case of pump combinations with support: Unscrew the support for the
pump and platform.
5. Hang, support, etc. the pump on the jack.
6. Loosen the connection between the pump and pump carriers fully.
7. Remove the pump from the pump housing, and loosen hexagon socket set
screws in the half-couplings.
8. Remove the “pump” half-coupling from the drive shaft.
9. Loosen the screw connection between the pump carrier and the motor ange
fully, and remove the pump carrier housing.
10. If necessary, remove the half-coupling of the motor.
11. Open the motor connection box, disconnect the connecting cable.
12. Loosen the pump motor screw tting at the installation site. Hang the motor on
the jack and lower.
The pump and motor are disassembled for transport.
14 Disposal / Recycling
Pumps and pump parts that are no longer used should be collected for proper
recycling of the various materials.
Dispose of uids in accordance with regulations, and note the safety data sheets!
Internal gear pumps
Disassembly and Disposal / Recycling
