1 High beams
The indicator light is on when the high beams are activated, see
page
126
.
2 Rotating beacon (optional equipment)
The light is on when the rotating beacon is activated. See page
176
.
3 DPF particulate filter, malfunction (yellow)
The light turns on in case of malfunction or failure of the DPF
particulate filter.
4 Applied parking brake
Turns on when the parking brake is applied.
5 Low engine oil pressure
NOTICE
Risk of machine damages
An instrument warning light and buzzer could indicate a serious
malfunction.
Stop the machine immediately and investigate the cause of the
signal.
The indicator light is on if the engine's oil pressure is too low.
6 Charging failure
Turns on when the alternator does not provide any charging
voltage. If the light turns on when operating, the cause must be
repaired, otherwise the batteries may be damaged.
7 Seatbelt reminder
Turns on if the engine is running and the operator sits in the
operator's seat without buckled seatbelt.
8 AdBlue®/DEF general warning (Only applies to
machines with engine alternative D11L or D11M)
The indicator light is on with a fixed light or flashes in case of
incorrect level, quality, or metering of AdBlue®/DEF.
9 Parked regeneration (Only applies to machines with
engine alternative D11M)
Turns on when it is time to run a parked regeneration, see page
193
10 High exhaust temperature (Only applies to
machines with engine alternative D11M)
HEST (High exhaust temperature). The indicator light is on when
parked regeneration is in progress and indicates that the
temperature of exhausts from the outlet pipe is higher than
normal.
46
Instrument panels
Instrument panel, centre
