Layers 2-12
Stagger each new layer so that the mats overlap the
joins in the layer below. Allow the new layer to extend
beyond (B)
the layer below by at least 50 mm (2") out
from the ring.
NOTICE! Allow the mats to reach up onto the stern if
this is possible.
P0012016
B
Installation, Volvo Penta IPS
47704162 10-2014 © AB VOLVO PENTA 77
