User’s Manual
EMB-9670/9673 Series User’s Manual
13
1.5 System Specifications
System
CPU
Supports µFC-PGA 478 / µFC-BGA 479 Intel® Pentium® M / Celeron® M
(Onboard Mobile Intel® Celeron® 600 MHz with 0K L2 Cache CPU for
EMB-9673 only)
FSB
400MHz
BIOS
Award 512 KB Flash BIOS
System Chipset
Intel® RG82855GME GMCH/FW82801DB ICH4
(Intel® RG82852GM GMCH/FW82801DB ICH4 for EMB-9673 only)
I/O Chip
Winbond W83627HF-AW
System Memory
One 184-pin DIMM socket supports up to 1 GB DDR 200/266/333 SDRAM
SSD
One CompactFlash Type I/II socket
Watchdog Timer
Reset: 1 sec.~255 min. ( 1 sec. or 1 min./step)
H/W Status Monitor
Monitoring system temperature, voltage, and cooling fan status. Auto
throttling control when CPU overheats.
Expansion
One PCI slot, one Mini PCI slot
I/O
MIO
4 x EIDE (Ultra DMA 100), 2 x FDD , 1 x LPT, 5 x RS-232, 1 x
RS-232/422/485, 1x K/B, 1 x Mouse
IrDA
115k bps, IrDA 1.0 compliant
USB
6 x USB 2.0 ports
DI/O
16-bit General Purpose I/O for DI and DO
