Vox Tonelab ST User Manual

2
Panel Tour for the guitarist (Top and rear
panels)
吉他演奏家的面板导航（前面板和后面板）
Here we’ll introduce you to the switches, controls, and connectors
on the ToneLab ST’s top panel.
这里我们将向你介绍 ToneLab ST 前面板上的开关，控制器，以及连接器。
Top panel
前面板
1. Amp section

Vox Tonelab ST Specifications

General

USB	No
MIDI	No
Power Supply	DC 9V
Effect Types	33
Amp Models	11
Inputs	1 x Instrument
Expression Pedal	Built-in
Outputs	1/4" line/headphone jack, 1/4" amp/line out jack
