Mounting the projector
The four adjustable feet under the chassis allow the projector to be lowered onto a flat surface without any danger of
hands being trapped between the chassis and the surface.
Figure 5 Adjustable feet
Ceiling mount
The projector is designed to be used on a flat surface, but it can also be suspended from a ceiling if your application
requires it. Three M4 mounting holes with a 0.7 mm pitch are provided under the projector to allow bolting to a ceiling
mounting plate.
Before installation, make sure that the surface, ceiling or rigging that is to support the
projector is capable of supporting the combined weight of all the projectors.
Figure 6 M4 Mounting holes
