Compact Single-Sensor Cameras
Compact single-sensor cameras: PRO variants are equipped with a USB connector
(Fig. 7 on page 12). OEM and COB variants also feature an additional 4-pin header
for trigger/strobe and a status LED ( Fig. 7 on page12).
Front View Top View
Fig. 7: Interfaces of a compact single-sensor camera VRmC-X+ PRO
1 USB Mini-B port
Side View Back View
USB
Sensor
T
G
G
S
Fig. 8: Interfaces of a compact single-sensor camera VRmC-X+ OEM
1 USB Mini-B port
2 4-pin header for trigger and strobe
3 Status LED
USB Cameras – User Guide12
