2 Overview
2.1 Camera Models
Single-Sensor Cameras VRm(F)C-X
Single-sensor cameras are equipped with one image sensor. The sensor board is
mounted directly onto the camera base unit, thus forming one compact unit. Single-
sensor cameras are available as board-level cameras (OEM versions), board-level
cameras with optics (COB versions) and as cameras with aluminium housing (PRO
versions).
All cameras are equipped with a sensor board and an interface board. Depending on
the image sensor, the camera may be equipped with an additional FPGA board (VRm-
FC-X models).
Front View Side View Back View
Sensor
Fig. 1: USB single-sensor camera (OEM) with FPGA board
1 Sensor board with image sensor
2 FPGA board (VRmFC-X cameras only)
3 Interface board
7USB Cameras – User Guide
