4.2.2 Cameras with Hirose DF14-15P Connector
Note
The following instructions apply to cameras equipped with a Hirose DF14 connec-
tor only. These are
• all multi-sensor cameras VRmMFC,
• all remote-sensor cameras VRmC-X-E,
• all board-level single-sensor cameras VRm(F)C-X.
It is assumed that you have ordered one of the optional cables “VRmDC/FC-X-
DF14-Open” or “VRmC-X OEM Interface Cable” ( 2.3 on page 13).
Connecting the camera:
1. Connect the supplied cable with the Hirose DF14 plug to the camera’s receptacle
( Fig. 5 on page10).
2. The other end of the cable splits into open ends or receptacles for trigger, strobe,
and external power supply, depending on the accessory kit you ordered ( Fig. 10
on page18). Connect trigger and strobe, if required.
f View the cable plan for a detailed description ( 7.1 on page 34).
3. Connect the USB cable to the camera’s USB port.
4. Continue with 4.3 on page 23 and read the information on power supply.
USB Cameras – User Guide20
