5
TEBS E
braking system
28
Internal loader
Hoses and pipes Diameter Max. length
Reservoir to trailer modulator min. ø 12 mm *)
Reservoir to relay valve min. ø 9 mm *)
Trailer modulator to relay valve max. ø 9 mm 10 m
Trailer modulator to brake cylinder min. ø 9 mm *) 10 m
Relay valve to brake cylinder min. ø 9 mm
min. ø 9 mm
3 m
3 m
*) The length of the hoses and pipes between the reservoir and modulator are only
allowed to be long enough for the response time as per ECE R13 annex 6 to be
met.
