GIO functions
77
6.5 RSS active signal (TEBS E2 or higher)
The TEBS E Modulator is equipped with the RSS function. While the RSS function
is active and there is an active RSS intervention, the stop lights on the vehicle are
not actuated actively.
In addition, the RSS active signal also makes it possible to actuate the stop lights
when the RSS function is activated by the TEBS E. For this purpose it is necessary
to parameterise this output via the GIO function.
Control may be carried out via a relay. The supply voltage for the brake lamps
must come from the 15-pin plug connection (ECE regulation).
Components
Component Part number
Relay Not part of WABCO's scope of supply
Universal cable 449 535 ... 0
Parameter setting
The settings are done via tab 8, General functions.
The GIO slots to use are defined in tab 11, connector.
6.6 ABS active signal (TEBS E2 or higher)
Vehicle type
All trailer vehicles
Purpose
During an ABS control process a retarder can be deactivated by a relay for exam-
ple to prevent the wheels from locking due to the retarder.
Function
WABCO switches the supply voltage to the selected GIO output when ABS control
is active during braking action.
Components
Component Part number
Relay Not part of WABCO's scope of supply
Universal cable 449 535 ... 0
Parameter setting
The settings are done via tab 8, General functions.
The GIO slots to use are defined in tab 11, connector.
