12.4 GIO diagram
GIO diagram
Open the WABCO website http://www.wabco-auto.com
.
Here click on Product catalogue INFORM.
Click the link Index.
Enter Wiring diagram in the Index field.
Click on the Start button.
Select Wiring diagram.
Click the link Product search.
Click the link Application.
Click on Trailer EBS E.
Name Diagram Vehicles
Immobilizer 841 701 227 0 All trailer vehicles
Electronic parking brake 841 701 264 0 Semitrailer
Standard 841 802 150 0 Semitrailer
Central axle trailer
2 lifting axles
Residual pressure maintenance on lifting axle 1
841 802 151 0 Semitrailer
Central axle trailer
External desired-pressure sensor 841 802 152 0 Semitrailer
Central axle trailer
Mechanical suspension 841 802 153 0 Semitrailer
Central axle trailer
Mechanical suspension 841 802 154 0 Drawbar trailer
Standard with 2 lifting axles 841 802 155 0 Semitrailer
Central axle trailer
Standard 841 802 156 0 Drawbar trailer
ECAS 1-point with two 1-circuit LACV 841 802 157 0 Semitrailer
Central axle trailer
ECAS 1-point with 1-circuit LACV and 2-circuit ECAS block 841 802 158 0 Semitrailer
Central axle trailer
TASC (RTR function) 841 802 159 0 Semitrailer
Central axle trailer
ECAS 1-point with 2 circuit ECAS block 841 802 190 0 Semitrailer
Central axle trailer
ECAS with 1-circuit LACV and residual pressure maintenance 841 802 191 0 Semitrailer
Central axle trailer
ECAS with single circuit LACV 841 802 192 0 Semitrailer
Central axle trailer
