5
TEBS E
braking system
34
Multi-voltage capable
functions
Component As of TEBS E version
Lifting axle control Lifting axle valve 463 084 050 0 TEBS E2
4S/2M+1M systems ABS relay valve 472 196 003 0 TEBS E2
4S/3M (drawbar trailer) EBS relay valve 480 207 202 0 TEBS E2.5
ECAS eTASC 463 080 5.. 0 TEBS E3
ECAS Valve rear axle
472 880 072 0
TEBS E4
TailGUARD ELEX TEBS E2
OptiTurn Tag axle valve
472 195 066 0
TEBS E4
Battery operation
Multi-Voltage systems can only be connected (via ELEX or directly) to 12 V batter-
ies in the trailer.
The charging function for the battery is only available while the trailer is supplied
with 12 V.
The Wake-up function is not available if the vehicle is supplied with 24 V.
Connecting 12 V components to GIOs other than those specified in the circuit dia-
grams can destroy system components.
