The ODR data can be protected from deletion by a user-defined password. The
password can be assigned by the TEBS E Diagnostic Software (ODR, password
management).
Statistical data
The statistical data is stored as sums or mean values throughout the unit's service
life or starting from the last time the Operating Data Recorder (ODR) was erased.
Statistical data is:
• Operating hours
• Number of trips
• Average load
• Overload counter (trips)
• Average braking pressure
• Number of brake actions
• Number of brake applications with pressure on yellow coupling head (without
CAN connection)
• Number of braking applications in 24N operation
• Number of brake applications with anti-jackknifing brake
• Number of park brake actuations
• Odometer and operating hours since the brake linings were last replaced
• Data pertaining to air suspension system and lifting axle activation
• Number of RSS brake applications or critical lateral acceleration
Trip accumulator
A trip has a driving route of at least 5 km and a minimum speed of 30 km/h. The
trip accumulator stores data from the last 200 trips.
The following data is recorded per trip:
• Kilometres at start of trip
• Distance driven in kilometres
• Operating hours at start of trip
• Driving hours
• Maximum speed
• Average speed
• Average control pressure
• Brake actuations
• Braking frequency
• Aggregate load at beginning of trip
• ABS brake applications
• RSS interventions, stage 1 (test brake)
• RSS interventions, stage 2 (deceleration brake application)
If a SmartBoard is connected, the trips are provided with time and date information.
Date and time can also be transferred from the towing vehicle.
Up to 600 trips can be stored.
The average lateral acceleration is additionally stored in curves per
trip.
