WABCO TEBS E1 - Temporary Deactivation of Automatic Level Control

6
TEBS E GIO functions
74
This function is also used to terminate all lifting axle functions, such as fully auto-
matic lifting axle control, traction help, OptiTurn etc. All lifting axles are lowered.
After the ignition is reset or as soon as the vehicle is moved at a speed of > 5 km/h
again, the automatic level control (+ including all lifting axle functions) is activated
again.
Connecting the components
The following components can be used for operation:
Item Component Figure Part number
A Switch Not part of WABCO's scope of supply
Alternatively: SmartBoard 446 192 11. 0
Cable for SmartBoard 449 911 ... 0
GIO universal cable 449 535 ... 0
Parameter setting
Activation of ECAS and assignment of components is done in tab 2, Vehicle and
tab 7, Air suspension.
More settings are made in tab 7, Air suspension, Extended ECAS parameters.
The GIO slots to use are defined in tab 11, connector.
