TEBS E
7
External systems
133
7.1.2 Connection from ISO 12098
The connection from ISO 12098 (for the actuation of the clearance lights) is done
in an existing and additional junction box see chapter 8.8 ‘Installation of Tail-
GUARD components’, page 153.
Wiring conc
ept for junction box
ELEX
Connections
GIO12
Cable colours
ISO 4141
ISO 12098
Pin
Terminal
Reversing lamp 1 Pink 8 L
CAN-High (optional) 2 White/Green 14
CAN-Low (optional) 3 White/Brown 15
Ground Light 4 White 4 31
Rear light left on 5 Black 5 58L
Marker light left off 6 Yellow/Black
Marker light right off 7 Yellow/Brown
Rear light right on 8 Brown 6 58R
The following products support a simplified connection to the vehicle's electrical
system:
• Aspöck: ASS3 with direct connection 76-5123-007
• Hella: EasyConn 8JE 340 847-001
