WABCO TEBS E4 - Page 179

TEBS E
10
Operation
179
WABCO Standard Mode
In this mode, the display is slightly more detailed than in ISO 12155 mode.
By illuminating individual rows of LEDs, the object orientation can be displayed for
right-middle-left behind the vehicle for individual objects.
If the object is not clearly detected, the object that is nearest the vehicle is dis-
played in case of doubt.
In WABCO standard mode, the green and yellow LEDs are also actuated when the
distance to the object is reduced. The lighting is constantly on during the procedure.
Detailed display can only occur for the levels in which 3 sensors are attached. If
only 2 sensors are attached in a level, completed LED rows are always displayed.
In the following table, the monitored areas and the display of the LED rows are
shown:
Object distance
LEDs ISO 12155 Mode WABCO Standard Mode
green > 300 cm Permanently ON
yellow 300 - 181 cm; flashing 2 Hz 300 - 150 cm; flashing 2 Hz
red 180 - 71 cm; flashing 4 Hz
0.8 m to braking point; flashing 6 Hz
from braking point; permanently on
150 - 76 cm; flashing 4 Hz
0.8 m to braking point; flashing 6 Hz
from braking point; permanently on
Brightness control
Pressing the F1 and F4 button at the same time switches to brightness control for
the LEDs. The brightness can be set in three stages (green: dark, yellow: medium
brightness, red: maximum brightness). You can use buttons F2 and F5 (+/-) to
switch between brightness settings.
If the Brightness control active parameter has been set in the TEBS E Diagnostic
Software, automatic mode with automatic light control can be selected (display in
LED filed: A).
Configuration
Trailer Remote Control is configured using the TEBS E Diagnostic Software.
Predefined configurations for button allocations
Configurable buttons Option 1
(WABCO Standard)
Option 2 Option 3
F1 Forced lowering ECAS Lifting ECAS Lifting
F2 Traction help Traction help Traction help
F3 Volume control Unloading level Volume control
F4 Immobilizer ECAS Lowering ECAS Lowering
F5 Manoeuvering assistance Tilt angle display Normal level II
F6 Switching off TailGUARD Road finisher brake OptiTurn/OptiLoad on/off
The Trailer Remote Control is delivered with the WABCO Standard Configuration
(Option 1). The buttons can also be configured any other way.
Exceptions:
• The immobilizer can only be programmed on F4 or F6.
• The volume and road finisher brake can only be programmed on F1, F3, F4 or
F6.
